331-7PF11-0AB0

Product Code: 331-7PF11-0AB0
Availability: 1000
Sold: 99

Price: $440.00

Qty:

Model	SM331 8AI Thermocouple
Product Description	8AI; Thermocouple temperature measurement modules; Input voltage range:±150mV
Power consumption
·Rate value	24V DC
·From backplane bus current consumption	100mA
·From L+	200mA
·Power loss	3W
The power of transmitter
·Supply current	/
·short-circuit protection	/
Number of analog inputs	8
Cable Length (Shielded)	Max:100m
Input type and input range
·voltage	±150mV(-32000~+32000)
·current(4wire)
·current(2wire)	/
·tesistance
·thermocouple	Type:T,E,J,K,N,R,S
·RTD	/
A/D resolution	16bits
Basic conversion time(per channel)	190ms
Interference frequency suppression	400/50/60Hz
Tolerance(Over entire temperature range)
·Voltage	±0.6%
·Current	/
·resistance	/
·temperature	±1℃
Interrupts
Diagnostic interrupt	Per group Yes,Configurable
Limit-value interrupt	Yes,Configurable
Isolation tested for contact
·Between channels	Yes
·Between channels and backplane bu	Yes
Front connector	40-pin
Dimensions(W x H x D)(mm)	40×125×120
Order Number	331-7PF11-0AB0
