FS-CIF13:equal to Omron CPM1-CIF11/CPM1-CIF12,the Peripheral port and RS232 to RS422/485 interface module for Omron PLC,It can directly use for CS / CJ, CQM1H, CPM2C series PLC

Product Code: FS-CIF13
Availability: 100
Sold: 99

Price: $94.00

Qty:

0 reviews | Write a review

Description Reviews (0)

FS-CIF13:equal to Omron CPM1-CIF11/CPM1-CIF12,the Peripheral port and RS232 to RS422/485 interface module for Omron PLC,It can directly use for CS / CJ, CQM1H, CPM2C series PLC

FS-CIF13 Manual

FS-CIF13 is the Peripheral port and RS232 to RS422/485 interface module for Omron PLC. Its function includes and even surpass Omron CPM1-CIF11 (peripheral port to RS422), CPM1-CIF12 (peripheral port to RS485), NT-AL001 (RS232 to RS422), 3G2A9-AL004-E (RS232 to RS422) module. It can directly use for CS / CJ, CQM1H, CPM2C series PLC, which eliminate the trouble that it needs CS1W-CN114 adaptor when using CPM1-CIF11 or CPM1-CIF12. It can connect PLC peripheral port or RS232 communication interface (automatic identification), the output is RS422 (4-wire full-duplex) or RS485 (2-wire half-duplex). It’s no need an external power supply, communication distance can be up to 2 Km.

The following is the FS-CIF13 and Omron CPM1-CIF11, CPM1-CIF12 and NT-AL001 comparison:

module function	FS-CIF13	CPM1-CIF11	CPM1-CIF12	NT-AL001 3G2A9-AL004-E
The connection with PLC	Peripheral port ,RS232	Peripheral port	Peripheral port	RS232
The connection with computer	RS232	No	No	RS232
Output	RS422 and RS485	RS422	RS485	RS422
External power supply	No	No	No	Need an external power supply
Communication indicator	yes	No	No	No
The largest communication distance	2000m	500m	500m	500m
The largest group networks	32	32	32	32

Technical details:

1,Can connect peripheral port, RS232 serial port of PLC and RS232 serial port of computer and other devices

2, Output is the 4-wire full-duplex RS422 interface and 2-wire half-duplex RS485 interface
3, No need external power
4, Communication cable should choose sectional area of over 0.5mm 2 shielded twisted pair
5, The largest communication distance is 2,000 meters
6, The largest group networks is 32(the hardware of the product itself can support 128 stations)
7, The largest communication rate is 115.2 Kbps, adaptive baud rate
8, With transient voltage suppression, can withstand the power of up to 600 W transient over-voltage, and resist the impact of ±15KV electrostatic discharge
9, Work temperature: -20 ~ 70 ℃
10, Installation: 35 mm standard rail installation and bolt hole installation
11, Dimension: 85 × 55 × 25
