eMT3150A

eMT3150A
eMT3150A eMT3150A eMT3150A
Product Code: eMT3150A
Availability: 9999
Sold: 99
Price: $0.10
Qty:

eMT3150A

Display
Display 15" TFT
Brightness (cd/m2) 350
Contrast Ratio 700:1
Color 16.2M
Resolution (W x H) 1024x768
Back Light LED
Back Light Life Time >50,000 hrs
Processor 32Bit RISC CPU 800MHz
Enclosure Aluminum
Touch Panel
Touch Panel Type 4-wire Resistive Type
Memory
Storage 256 MB
RAM (RAM) 256 MB
I/O ports
SD Card Slot SD/SDHC
USB Host USB 2.0 x 1
USB Client USB 2.0 x 1
Ethernet Port 10/100 Base-T
COM Port COM1(RS-232/RS-485 2W/4W), COM3(RS-232/RS-485 2W) Supports MPI 187.5K
Video Input Port NTSC/PAL RCA x 2
Audio Audio Line Out - 3.5 mm jack x 1
CAN bus CANopen Protocol
Power
Input Power 24±20% VDC
Power Consumption 900m A@24V
RTC Built-in
Specification
Panel Cutout (W x H) 352 x 279 mm
Weight (kg) Approx. 2.75 kg
Certification
CE Compilies with EN 55022:2006+A1:2007 , EN 61000-3-2:2006+A2:2009 .EN 61000-3-3:2008, EN 55024:1998+A1:2001+A2:2003
FCC Comply with FCC class A
UL UL 508 type 4X
Operation
Voltage Resistance 500VAC (1 min)
Isolation Resistance Exceed 50MΩ at 500VDC
Vibration Endurance 10 to 25 Hz(X,Y,Z direction 2G 30 minutes)
Protection Structure IP65 front panel (O ring seal)
Storage Temperature -20°~70°C (-4°~158°F)
Operating Temperature 0°~50°C (32°~122°F)
Operation Humidity 10~90% RH (non-condensing)
